HF1220SB.LRHE5

High Output Neon Flex 12x20mm | 5w p/mtr Long Run – 20m

  • High efficiency: Up to 62 lm/W

  • Max run length: 20 metres from a single feed

  • Low power usage: 5W/m

  • Luminous output: Up to 310 lm/m

  • High color rendering: CRI >90, R9 >50

  • Flexible side bend design for smooth curves and letters

  • Durable 12x20mm profile with a 150mm min. bend diameter

  • IP67 waterproof silicone body – UV, salt, and chemical resistant

  • 50mm cut unit for modular installs

  • 24V DC constant voltage

  • Available CCTs: 2700K, 3000K, 4000K, 5000K, 6000K

The HF1220SB.LRHE5 from the HELIFLEX collection is a high-efficiency, long-run LED neon flex engineered for performance and endurance. With an output of up to 62 lm/W, a low 5W/m power consumption, and a continuous run capacity of 20 metres, this 12x20mm profile is designed for demanding side-bending applications.

Crafted from durable, IP67-rated silicone, the HF1220SB.LRHE5 offers superior UV, salt, and impact resistance, making it ideal for both indoor and outdoor projects. Its side bend orientation allows for clean curves and precise outlines in creative installations like signage, architectural lighting, retail accents, and more.

Datasheet

HF1220SB.LRHE5_Heliflex_side_bend_horizontal_bend_long_run_high_effeciency_catalogue_data_sheet_100625
